flat square bottle printing machine

Introduction:factory supply semi automatic screen printer flat square bottle printing machine

factory supply semi automatic screen printer flat square bottle printing machine


Machine features

1, This machine is specially designed to print on the cylindrical, cone and oval objects, such as plastic bottles, glass, caps and so on.

2, Installed with internationally reputed components, controlled by micro-computer to ensure the operation easy and simple.

3, This machine can print several colors in the same objects with accurate registration between colors. Printing chuck is driven by a gear and a rack.

4, We can customize machine according to the special products.



Specifications:

Printing Product Size

Diameter

15mm-100mm

Height

20mm-250mm

Maximum Printing Area(L×W)

250mm×200mm

Maximum Running Speed

2100cycle/hour

Compressed Air Pressure Requirement

4-6bar

Machine Dimension(L×W×H)

750mm×950mm×1250mm

Total Weight

135kg
