Introduction:CO2 Laser Marking Machine
1) High precision marking, swift, engraving depth controllable.
2) Applied on most of non-metal material.
3) Excellent beam quality, high photoelectric conversion efficiency, good performance and can be competent at fine processing.
4) Windows interface adopted, compatible with CORELDRAW, AUTOCAD, PHOTOSHOP, etc.
5) Support PLT,PCX, DXF,BMP and other formats, execute SHX, TTF font directly, support automatic code, serial number, batch number, two-dimensional bar code marking, and garphic anti marking function available.
NO | Model | RF-F-CO2 |
1 | Working size | 100X100/ 200X200/ 300X300mm |
2 | Laser Power | 60W/80W/90W/100W/150W Reci or US Synrad metal laser tube |
3 | Galvo system | High quality Galvo scanning system |
4 | Laser Power Control | 0-100% Software Controlling |
5 | Axial Speed | 0-7000mm/s |
6 | Motion System | Servo Motor/ stepper motor |
7 | Repeat Location Accuracy | ± 0.01mm |
8 | Voltage | 110V/220V, 50HZ/60HZ |
9 | Cooling System | Industrial water chiller |
10 | Min character | 0.3mm |
11 | User Control | Digital Screen Panel |
12 | Operate system | Windows XP/7/8/10 |
13 | Format Support | PLT/DXF/AI/SDT/BMP/JPG/JPEG/GIF/TGA/PNG/TIF/TIFF CorelDraw/PhotoShop/AutoCAD/Illustrator |
14 | Software | Original EZCAD |
15 | Package size | Length*width*height :1860x760x1320mm Gross weight:230kgs |
