Introduction:Type SOOW UL/CSA is designed for extra hard usage on industrial equipment, heavy tools, battery chargers, portable lights welding leads, marine dockside power, power extensions and mining applications, it is permitted for use as specified by Article 400 a
APPLICATION
Type SOOW UL/CSA is designed for extra hard usage on industrial equipment, heavy tools, battery chargers, portable lights welding leads, marine dockside power, power extensions and mining applications, it is permitted for use as specified by Article 400 and related articles of the 2011 NEC.
CONSTRUCTION
Rated Voltage: 600V
Conductor: Class K stranded bare copper per ASTM B-174
Insulation: Premium-grade, oil-resistant EPDM 90˚C
Outer Sheath: Black CPE compound -40˚C to +90˚C + class 1.4, table 11, UL 62
CORE IDENTIFICATION
2 core---Black, White
3 core---Black, White, Green
4 core---Black, White, Red, Green
5 core---Black, White, Red, Orange, Green
STANDARDS: ASTM B-174, UL Flexible Cord - UL Subject 62, CSA Flexible Cord - C22.2-49, MSHA
APPROVALS: UL, CSA, MSHA
FEATURES
★ UL Listed and CSA Certified for indoor and outdoor use
★ Excellent flexibility in cold temperatures
★ Ozone-sunlight (UV)- and weather-resistant
★ Water, oil, moisture, heat, abrasion and cut resistance
★ Good tensile strength, elongation and aging characteristics
★ Flame retardant per to FT2, MSHA
★ Temperature range from -40°C to +90°C
PACKAGING: 250ft, 500ft, 1000ft, 5000ft etc.
SIZE RANGE
| Cable Type | No.of Cores | Size(AWG) |
| SOOW | 2 | 18~2 |
| SOOW | 3 | 18~2 |
| SOOW | 4 | 18~2 |
| SOOW | 5 | 18~2 |
