Introduction:540 High Speed Spring Coiling Machine adopts Japan servo motor and TaiWan control system YiTu Brand). Feeding axis, Cam axis, Up-cutter axis, Under-cutter axis and Pitch axis.
| Axis count | 4/5 axis |
| wire size range | ￠1.6-4.5mm |
| Max feeding speed | 96m/min |
| Spring index | 3 |
| Feeding Wheel count | 3 pairs |
| Feeding motor | 5.5KW |
| Upper cutter motor | 2.7KW |
| Under cutter motor | 2.7KW |
| Cam motor | 2.7KW |
| Pitch motor | 1.5KW |
| Dimension | 12520*1400*1850mm |
| Weight | 1900KG |
| Power | 3-380VAC |
