Introduction:gprs printer sms usb and ethernet thermal printer MQTT Could Printing Solution
gprs printer sms usb and ethernet thermal printer MQTT Could Printing Solution
Function
gprs printer sms
Easy paper loading
Printing images and characters with high speed, the best printing quality and reliable performance
Support GB18030 simplified Chinese, traditional Chinese, buyer optional languages
Support printer states minitor function, control printers states at any time.
Full/Partial option, no paper jamming problem, multiple choice for customer
Driving high speed download printing mode, support linux system
Compatible with Epson ESC/POS Commands.
Parameter
Printing method | Direct thermal |
Print width | 76mm |
Column capacity | 576 dots/line 512 dots/line |
Printing speed | 250mm/s |
Interface | Serial+Lan+gprs |
Printing paper | 79.5±0.5mm×φ80mm |
Line spacing | 3.75mm (Adjustable by commands) |
Column number | 80mm paper: Font A - 42 columns or 48 columns/Font B - 56 columns or 64 columns/ |
Character size | ANK,Font A:1.5×3.0mm(12×24 dots) Font B:1.1×2.1mm(9×17 dots)Chinese,traditional Chinese:3.0×3.0mm(24×24 dots) |
Cutter | |
Auto cutter | Full or partial ( Optional) |
Barcode Character | |
Extension | PC347(Standard Europe),Katakana,PC850(Multilingual),PC860(Portuguese),PC863(Canadian-French),PC865(Nordic), |
Barcode types | UPC-A/UPC-E/JAN13(EAN13)/JAN8(EAN8)/ |
2D code | QR Code |
Buffer | |
Input buffer | 2048k bytes |
NV Flash | 256k bytes |
Power | |
Power adaptor | Input:AC 110V/220V, 50~60Hz |
Power source | Output:DC 24V/2.5A |
Cash drawer output | DC 25V/1A |
Physical characteristics | |
Weight | 1.70KG |
Dimensions | 190×145×150mm (D×W×H) |
Environmental Requirements | |
Work environment | Temperature (0~45) humidity(10~80%) |
Storage | Emperature(-10~60℃) humidity(10~80%) |
Reliability | |
Cutter life | 1million cuts |
Printer head life | 100KM |
