Plastic Pellet Machine

Introduction:Plastic Pellet Machine

Pellet Machine (PE)

1.The production line is used for recycling PP,PE film ,with conveying ,crushing & granulating function.
2.Easy operation,hight output ,best quality with competitive price .

Techinical Details :

	Item	HXSJ140/140-TR900
Conveying belt	size (width*length)	650*4000mm
	Motor power	0.75kw
main extruder	Screw dia	Ø140mm
	Screw Length	3600mm
	Screw L/D	25:1
	No of exhauxing hole	single
	Material for screw	38CrMoAlA, Nitriding treatment
	Material for barrel	40Cr ,Nitriding treatment.
	Gear box	55# gear box
	Main Motor	90kw-4pole
	Heating zone	9zone
	Heating power	55kw
	Heating means	Stainless steel and quartz heater
	Cooling means	Copper tube with circular water
	Mode of mesh changing	Ø280*280mm double hydraulic screen exchanger
peripherics	Cutter	27knife cutter 1.5kw , inverter
	Dewater device	Vertical dewater device,driven power 4kw
	Storage hopper	Equiped with.
	Hydraulic drive system	Double valve hydraulic station, power 4kw.
Total power		206kw
Out put		350-450kg/h
