Introduction:2D Wire Bending Machine is suitable for different wire diameter, aluminum wire, iron wire, copper wire, stainless steel wire rolled into different circle diameter or different etc.
（Model No.） | BL-2D-41000 |
Input OD of Wire | 4.0-10.0mm |
Maximum wire feed speed | 90 |
No. of Axis | 4 |
No.of Feeding Round | 3 Pairs |
The total power | 9.5KW |
Wire feeding power | 4.5 KW |
The lifting power | 1 KW |
Cut off the power | 2.0KW |
Bending power | 2.0 KW |
Size（L*W*H） | 3000*1850*1750mm |
Weight of Machine | 2800KG |
Suitable for different wire diameter, aluminum wire, iron wire, copper wire, stainless steel wire rolled into different circle diameter or different arc. It is usually used in wire products, refrigerator bracket, kitchen shelf, fan net ring, crafts, pet cage and other industries.
The diameter of the processing line is 4.0-10.0mm, and the steel wire is 4-8mm, which is suitable for steel wire and iron wire.
Products Are mainly Used In Automobiles, Kitchenware, Garden Tools, Supermarket Shelves, Furniture, etc.
